The strong corrosion resistance of 409 stainless steel coil comes from its core element - chromium (Cr) content, which is greater than or equal to 10%; it contains a small amount of titanium, which reduces the risk of intergranular corrosion; it contains very little nickel, which is relatively low in cost; it has a certain degree of corrosion resistance, which is reflected in dry, slightly humid or non-corrosive media; it is not easily oxidized at high temperatures, and has good heat resistance and oxidation resistance; it has good ductility and good weldability.

Email : contact@zunkaisteel.com
Phone/Whatsapp : +15169002039
Addess : Huaiyin District,Jinan City,Shandong,China.

GET A QUOTE

Description

0.4/0.6/0.5 430 2ba/N4 Stainless Steel Coil

409 stainless steel coil is a ferritic stainless steel. Its coil form facilitates continuous processing, cutting, or stamping. Its core properties are low cost, excellent heat resistance, good basic corrosion resistance, and strong machinability.
The corrosion resistance of 409 stainless steel coil stems from its core element, chromium (Cr), which is >= 10%. It also contains a small amount of titanium, which reduces the risk of intergranular corrosion. Its minimal nickel content contributes to its low cost. It offers moderate corrosion resistance in dry, slightly humid, or non-corrosive media. It is resistant to oxidation at high temperatures, exhibiting excellent heat and oxidation resistance. It also has good ductility and weldability.
The core application area of 409 stainless steel coil is the automotive industry, particularly for exhaust system components. Other applications include heat exchange and HVAC equipment, industrial ventilation and exhaust ducting, and low-cost structural and protective components.

Chemical Composition about stainless steel coil

Stainless Steel Coil/Sheet/Plate Information
Technique	Surface Finish	Grade Series	Thickness(mm)	Width(mm)
				Main Dimension
				20-850	1000	1219	1240	1250	1500
Hot Rolled	No.1 / 2E	201/304/316L	2.2-12.0	√	√	√	√		√
Cold Rolled	2B	201/304/316L	0.25-3.0	√	√	√	√	√	√
	2B	410S/430	410S/430	0.25-3.0	√	√	√		√
	No.4 /Hairline Mirror / Linen SB	201/304/316L	0.22-3.0	√	√	√	√	√	√
	No.4 /Hairline Mirror / Linen SB	410S/430	410S/430	0.25-3.0	√	√	√	√	√
	BA	201/304	0.2--1.8	√	√	√	√	√	√
	BA	410S/430	410S/430	0.25-3.0	√	√	√
	2BA	304/410S/430	0.25-2.0	√	√	√	√
If you need, we can customize the size according to your requirements

Grade	C	Si	Mn	P	S	Ni	Cr	Mo
201	≤0.15	≤0.75	5.5-7.5	≤0.06	≤0.03	3.5-5.5	16.0-18.0	-
202	≤0.15	≤1.0	7.5-10.0	≤0.06	≤0.03	4.-6.0	17.0-19.0	-
301	≤0.15	≤1.0	≤2.0	≤0.045	≤0.03	6.0-8.0	16.0-18.0	-
302	≤0.15	≤1.0	≤2.0	≤0.035	≤0.03	8.0-10.0	17.0-19.0	-
304	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	8.0-10.5	18.0-20.0	-
304L	≤0.03	≤1.0	≤2.0	≤0.035	≤0.03	9.0-13.0	18.0-20.0	-
309S	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	12.0-15.0	22.0-24.0	-
310S	≤0.08	≤1.5	≤2.0	≤0.035	≤0.03	19.0-22.0	24.0-26.0	-
316	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	10.0-14.0	16.0-18.0	2.0-3.0
316L	≤0.03	≤1.0	≤2.0	≤0.045	≤0.03	12.0-15.0	16.0-18.0	2.0-3.0
321	≤0.08	≤1.0	≤2.0	≤0.035	≤0.03	9.0-13.0	17.0-19.0	-
630	≤0.07	≤1.0	≤1.0	≤0.035	≤0.03	3.0-5.0	15.5-17.5	-
631	≤0.09	≤1.0	≤1.0	≤0.030	≤0.035	6.50-7.75	16.0-18.0	-
904L	≤2.0	≤0.045	≤1.0	≤0.035	-	23.0-28.0	19.0-23.0	4.0-5.0
2205	≤0.03	≤1.0	≤2.0	≤0.030	≤0.02	4.5-6.5	22.0-23.0	3.0-3.5
2507	≤0.03	≤0.80	≤1.2	≤0.035	≤0.02	6.0-8.0	24.0-26.0	3.0-5.0
2520	≤0.08	≤1.5	≤2.0	≤0.045	≤0.03	0.19-0.22	0.24-0.26	-
410	≤0.15	≤1.0	≤1.0	≤0.035	≤0.03	-	11.5-13.5	-
430	≤0.12	≤0.75	≤1.0	≤0.040	≤0.03	≤0.60	16.0-18.0	-

Product Parameters

ITEM	Stainless Steel coil
Brand	RONSCO,BAOSTEEL, JISCO, TISCO, etc.
Grade	201.202.301.302.304.304L.310S.316.316L.321.430.430A.309S.2205.2507.2520.430.630.631 .410.440.904Lect. Or Customized
Certificate	SGS,BV,IQI,TUV,ISO,etc
Length	As Customer requirements
Surface	No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film.
Standard	GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
Package	Standard export sea-worthy packing or customized
MOQ	5 Ton

Surface treatment

Surface Finished	Characteristics	Characteristics
NO.1	Finished by hot-rolling, smoother and pickling, characterized by white pickled surface.	Chemical industry equipment, Industrial tanks.
2B	Finished by anneal treatment, pickling after cold rolling, followed by skin pass line to more brighter and smoother surface.	General application medical instruments, Tableware.
BA	Bright anneal treatment after cold rolling.	Kichen utenstil, Kitchen ware,Architectural purpose.
NO.4(Satin)	Finished by incontinuous linear brushing	Architecture,industries,Escalators, Kitchen ware, Vehicles.
Hairline	Finished by continuous linear brushing	Architecture,industries,Escalators, Kitchen ware, Vehicles.
8K(mirror)	A mirror-like reflective surface by polishing with finer abrasives over 800 mesh.	Refletor, Mirror, Interior- Exterior decoration for building.

Mechanical Properties

Tensile Strength Kb (MPa)	Yield Strength σ0.2 (MPa)	Elongation D5 (%)	Hardness
≥ 520	≥ 205	≥ 40	≤ 187HB ;≤ 90HRB;≤ 200HV

Physical Performance

Density(g/cm³)	Modulus of Elasticity(Gpa)	Coefficient of Thermal Expansion(10^-6/°C)	Coefficient of Thermal Conductivity(W/m*K)	Resistivity(ΜΩ. cm)
8.03	193	16.9	16.2	72
