317L stainless steel is a lower carbon version of 317 stainless steel, which means it has better corrosion resistance and higher creep strength at high temperatures. It contains molybdenum, nickel and chromium as main alloying elements.

Email : contact@zunkaisteel.com
Phone/Whatsapp : +15169002039
Addess : Huaiyin District,Jinan City,Shandong,China.

GET A QUOTE

Description

0.4/0.6/0.5 430 2ba/N4 Stainless Steel Coil

317L stainless steel has a very special composition that gives it its unique properties and characteristics. This type of stainless steel is composed of a mix of elements such as chromium, nickel, molybdenum, and carbon. Chromium is the main component of 317L stainless steel and has good corrosion resistance. A protective layer on the metal surface manages to prevent rust and staining. Chromium also plays an important role in providing corrosion resistance and increasing high-temperature strength. Molybdenum improves resistance to pitting corrosion from chloride solutions that are commonly found in harsh environments such as seawater or chemical processing plants. Carbon content helps increase hardness but can reduce weldability if not controlled properly. The precise balance between these elements ensures that 317L stainless steel performs better than traditional austenitic grades when used in high-temperature, corrosive environments.

Chemical Composition about stainless steel coil

Stainless Steel Coil/Sheet/Plate Information
Technique	Surface Finish	Grade Series	Thickness(mm)	Width(mm)
				Main Dimension
				20-850	1000	1219	1240	1250	1500
Hot Rolled	No.1 / 2E	201/304/316L	2.2-12.0	√	√	√	√		√
Cold Rolled	2B	201/304/316L	0.25-3.0	√	√	√	√	√	√
	2B	410S/430	410S/430	0.25-3.0	√	√	√		√
	No.4 /Hairline Mirror / Linen SB	201/304/316L	0.22-3.0	√	√	√	√	√	√
	No.4 /Hairline Mirror / Linen SB	410S/430	410S/430	0.25-3.0	√	√	√	√	√
	BA	201/304	0.2--1.8	√	√	√	√	√	√
	BA	410S/430	410S/430	0.25-3.0	√	√	√
	2BA	304/410S/430	0.25-2.0	√	√	√	√
If you need, we can customize the size according to your requirements

Grade	C	Si	Mn	P	S	Ni	Cr	Mo
201	≤0.15	≤0.75	5.5-7.5	≤0.06	≤0.03	3.5-5.5	16.0-18.0	-
202	≤0.15	≤1.0	7.5-10.0	≤0.06	≤0.03	4.-6.0	17.0-19.0	-
301	≤0.15	≤1.0	≤2.0	≤0.045	≤0.03	6.0-8.0	16.0-18.0	-
302	≤0.15	≤1.0	≤2.0	≤0.035	≤0.03	8.0-10.0	17.0-19.0	-
304	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	8.0-10.5	18.0-20.0	-
304L	≤0.03	≤1.0	≤2.0	≤0.035	≤0.03	9.0-13.0	18.0-20.0	-
309S	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	12.0-15.0	22.0-24.0	-
310S	≤0.08	≤1.5	≤2.0	≤0.035	≤0.03	19.0-22.0	24.0-26.0	-
316	≤0.08	≤1.0	≤2.0	≤0.045	≤0.03	10.0-14.0	16.0-18.0	2.0-3.0
316L	≤0.03	≤1.0	≤2.0	≤0.045	≤0.03	12.0-15.0	16.0-18.0	2.0-3.0
321	≤0.08	≤1.0	≤2.0	≤0.035	≤0.03	9.0-13.0	17.0-19.0	-
630	≤0.07	≤1.0	≤1.0	≤0.035	≤0.03	3.0-5.0	15.5-17.5	-
631	≤0.09	≤1.0	≤1.0	≤0.030	≤0.035	6.50-7.75	16.0-18.0	-
904L	≤2.0	≤0.045	≤1.0	≤0.035	-	23.0-28.0	19.0-23.0	4.0-5.0
2205	≤0.03	≤1.0	≤2.0	≤0.030	≤0.02	4.5-6.5	22.0-23.0	3.0-3.5
2507	≤0.03	≤0.80	≤1.2	≤0.035	≤0.02	6.0-8.0	24.0-26.0	3.0-5.0
2520	≤0.08	≤1.5	≤2.0	≤0.045	≤0.03	0.19-0.22	0.24-0.26	-
410	≤0.15	≤1.0	≤1.0	≤0.035	≤0.03	-	11.5-13.5	-
430	≤0.12	≤0.75	≤1.0	≤0.040	≤0.03	≤0.60	16.0-18.0	-

Product Parameters

ITEM	Stainless Steel coil
Brand	RONSCO,BAOSTEEL, JISCO, TISCO, etc.
Grade	201.202.301.302.304.304L.310S.316.316L.321.430.430A.309S.2205.2507.2520.430.630.631 .410.440.904Lect. Or Customized
Certificate	SGS,BV,IQI,TUV,ISO,etc
Length	As Customer requirements
Surface	No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film.
Standard	GB, AISI, ASTM, ASME, EN, BS, DIN, JIS
Package	Standard export sea-worthy packing or customized
MOQ	5 Ton

Surface treatment

Surface Finished	Characteristics	Characteristics
NO.1	Finished by hot-rolling, smoother and pickling, characterized by white pickled surface.	Chemical industry equipment, Industrial tanks.
2B	Finished by anneal treatment, pickling after cold rolling, followed by skin pass line to more brighter and smoother surface.	General application medical instruments, Tableware.
BA	Bright anneal treatment after cold rolling.	Kichen utenstil, Kitchen ware,Architectural purpose.
NO.4(Satin)	Finished by incontinuous linear brushing	Architecture,industries,Escalators, Kitchen ware, Vehicles.
Hairline	Finished by continuous linear brushing	Architecture,industries,Escalators, Kitchen ware, Vehicles.
8K(mirror)	A mirror-like reflective surface by polishing with finer abrasives over 800 mesh.	Refletor, Mirror, Interior- Exterior decoration for building.

Mechanical Properties

Tensile Strength Kb (MPa)	Yield Strength σ0.2 (MPa)	Elongation D5 (%)	Hardness
≥ 520	≥ 205	≥ 40	≤ 187HB ;≤ 90HRB;≤ 200HV

Physical Performance

Density(g/cm³)	Modulus of Elasticity(Gpa)	Coefficient of Thermal Expansion(10^-6/°C)	Coefficient of Thermal Conductivity(W/m*K)	Resistivity(ΜΩ. cm)
8.03	193	16.9	16.2	72
